60HZ Refrigerated Air Dryer

60HZ Refrigerated Air Dryer
CategoriesKDH series small refrigerated air dryer
BrandKL
ModelKDL-20F
Cooling typeAir cooled
RefrigerantR134a,R410a,R22
EvaproatorPlate heat exchanger
Max inlet temperature45°C
Ambient temperature40°C
Dew point2-10°C
Working pressure7-10Bar
Voltage220V/50Hz
FOB portShanghai、Ningbo
Terms of PaymentL/C, T/T
Update TimeSeptember 23,2023
Detail Information

KDH Series Refrigerated Air Dryer

KDH series :

                     Max inlet temperature:80oC

                     ambient temperature≤42oC

                     working pressure:7-10Bar

                     DEE-POINT TEM:2-10oC

Comprehensive presentation





Specifications


  Model        Flow  CapacityPower Cons.(kw)Conn.       DimensionsWeight
m3/minm3/hCFM(BSP)L (mm)W(mm)H (mm)(kg)
KDL-10F1.696560.471"50041568045
KDL-20F2.6156920.851"63045079050
KDL-30F3.82281341.041"63045079055
KDL-50F63602121.651 1/2"77053089070
KDL-60F74202471.651 1/2"82053089080
KDL-75F8.55103001.671 1/2"87058089090
KDL-100F11.56904062.052"1180580870120
KDL-120F13.58104762.32"9507301130140



Delivery time
Generally15 working days after the order confirmed

Packaging
1) Custom package request is appreciate.
2) Standard package: Corrugate carton


Pls kindly send it with below technical  information , that's better for us quickly feedback your inquire:

 1) Flow rate:    _____Nm3/min

 2) Working pressure:      _____Bar

 3) Connection:    _____

 4) Inlet temperautre :   ______

5) Ambient temperature:______

6) Dew-point: _______

 7) others
